Connect iPad with MIDI

There are different ways to connect the iPad with MIDI.

Older iPads to devices with USB-MIDI connection​

Many iPad models do not yet have a USB-C connection, but a Lightning or even a 32-pin connection.

Many MIDI adapters and some devices (keyboards, etc.) have a USB connection for MIDI.

Because the older iPad models do not have a USB connection by default, an adapter is needed to extend the iPad with a USB connection. Apple calls this adapter the "iPad Camera Connection Kit."

USB-MIDI adapters and USB-MIDI devices can then be connected to it, provided they are compatible with Apple.

Keyboard with direct USB-MIDI connection Keyboard with DIN 5-Pin MIDI connection

Newer iPads to devices with USB-MIDI connection​

Newer iPad models have a USB-C connection instead of the Lightning connection.

Therefore, it is no longer necessary to use an adapter to extend the iPad with a USB connection.

With a suitable cable with a USB-C connection, you can directly connect the iPad to the device.

MIDI adapters that connect directly to the iPad​

Some MIDI adapters can be connected directly to older iPads without an adapter.

These include, for example:

  • iConnectMIDI2+ by iConnectivity
  • iRig MIDI Version 1+2 by IK Multimedia
  • ioDock by Alesis
  • iStudio is202 by Behringer
  • ...

With these, the iPad can also be powered while in MIDI operation (all listed above except iRig MIDI Version 2).

There are also a few simple, small MIDI keyboards that can be directly connected to the iPad.

Wireless via Bluetooth or WLAN​

There are also wireless MIDI adapters that can be connected to the iPad wirelessly via Bluetooth (Bluetooth MIDI LE) or WLAN.

Wireless MIDI connection

These include, for example:

  • mi.1 by QuiccoSound (Bluetooth)
  • PUC wireless MIDI interface (WLAN)
  • Yamaha Tyros 5 Keyboard with WLAN stick
  • Yamaha MD-BT01
  • Yamaha UT-BT01
  • Zivix PUC+
